14
English
2.4 Electrical diagram
2
.3 Product identification data
The rating plate gives the data and ratings of the appliance.
I
f the rating plate is missing, has been removed or tampered with,
any installation and maintenance operations are made difficult due
to lack of product identification.
In the event of damage, please ask the Piazzetta after-sales service
c
entre for a copy.
P
roduct name
S
erial number
D
T2030624-00
DT2030072-00
EXTERNAL
THERMOSTAT
Smoke fan
Capacitor
PILOT LIGHT
F
N
S
MOKE
SMOKE
POINTS
POINTS
PILOT LIGHT
PILOT LIGHT
FUEL-LOADING CHUTE
FUEL-LOADING CHUTE
AL . 2
AL . 1
N
Fuel-loading chute
80
1
P
2
180
1
P
2
THERMOSTATS
G
N
L
POWER
THERMOELEMENT ABGASE
SMOKE SENSOR
ROOM SENSOR
Room fan
LN
FAN 2
Brown
Light blue
Blue
Black
Brown
Blue
Red
Black
Black
Light blue
Light blue
Brown
White
White
White
Weiß
Grau
Red
Red
Black
Black
Black
Yellow-green
Yellow-green
Yellow-green
Flat cable
N.A. PRESSURE SWITCH
N. C.
N. C.
32
1
2
3
4
5
6
7
8
9
10
11
12
CN2
IC10
SERIAL
DB 9
FAN 1
Display
