Superior MIRELLA - Technical Characteristics and Specifications

SUPERIOR
®
English
13
2.0 TECHNICAL CHARACTERISTICS AND SPECIFICATIONS
DT2010102-01
2
.1 Technical data
• Fuel: Natural wood pellets • Length: < 30mm
•
Diameter: ca. 6 - 6.5 mm
• Water content: ca. 6% - 8%.
Data obtained under laboratory conditions with pellets of heat production rated at 5kwh/kg.
2.2 Plan (cm)
U
NIT
M
IRELLA
H
ourly fuel consumption (max/min)
k
g/h
1
,4 / 0,75
Nominal thermal power (max/min) kW 5,5 / 2,5
Efficiency % > 80
Draught when connected to chimney Pa 10÷15
Fuel tank capacity
kg / (l)
15 / (23)
E
lectrical power supply
V 2
30
Frequenz Hz 50
Maximum power rating W 320
Power rating (max / min) W 110 / 70
Exhaust outlet diameter cm Ø 8
Fresh air intake with minimum useful section cm
2
100
Weight with majolica kg 85
Packing cladding kg 95
Packing sizes (DxWxH) cm 58,5X54X119
DT2030071-00
15 7
17,5
94
43
46
Diameter Ø 8
