2-2
Add-on Card User's Guide
2-2 Front Connector and LED Defi nitions
1. LAN ports
LAN ports allow the Add-on card to connect a maximum of two network cables (CX4
connectors). Each LAN port provides up to 10 gigabits per second connection speed
and require CX4 copper-based cables for maximum throughput.
The ports are designated Port 1 and Port 2.
2. LAN Port LEDs
Each LAN port has a corresponding bi-level, dual-color LED which indicates con-
nection, activity, and connection speed (in Giga-bits/second). Review the table
below for LEDs defi nitions.
Color Defi nition
Yellow 1Gb link speed
Blinking yellow 1Gb Activity
Green 10Gb link speed
Blinking Green 10Gb Activity
