Supermicro C7Z270-CG - Jumpers and Connectors

Package contents
• One (1) Supermicro Motherboard
• Four (4) SATA Cables, One (1) I/O Shield
• One (1) Quick Reference, One (1) Driver CD
Connector Description
AUDIO FP Front Panel Audio Header
B1 Onboard Battery
COM1 COM1 Port Header
I-SATA0~5
(Intel
®
Z270) Serial ATA (SATA 3.0) Ports 0~5 (6Gb/sec)
JD1 Speaker/buzzer (Pins 1~4: External Speaker, Pins 3~4: Buzzer)
JF1 Front Panel Control Header
JL1 Chassis Intrusion Header
JLED1 Power LED Indicator Header
JPW1 24-pin ATX Main Power Connector (Required)
JPW2 +12V 8-pin CPU power Connector (Required)
JSD1 SATA DOM (Disk On Module) Power Connector
JSPDIF_OUT Sony/Philips Digital Interface Format (S/PDIF) Out Header
JSTBY1 Standby Power Header
JTPM1 Trusted Platform Module (TPM) Header
PCI-E M.2 CONNECTOR 1, 2* PCI-E M.2 Connectors 1 and 2, small form factor devices and other portable
devices for High speed NVMe SSDs
U.2 CONNECTOR 1, 2* U.2 Connector 1 and 2, for 2.5” SSD Drives
USB 2/3, USB 4/5, USB 6/7 Front Panel Accessible USB 2.0 Headers 2/3, 4/5. 6/7
USB 12/13 (3.0) Front Panel Accessible USB 3.0 Header 12/13
SYS FAN 1,2,3 CPU FAN 1,2 System/CPU Fan Headers
Jumpers and Connectors
Jumpers
Jumper Description Default
CLEAR CMOS Clear CMOS Switch Push Button Switch
JBR1 BIOS Recovery Switch Pins 1-2 (Disable)
JBT1 Clear CMOS (on board) Short pads to clear CMOS
JI
2
C1/JI
2
C2 SMB to PCI Slots On (Enabled)
JPAC1 Audio Enable Pins 1-2 (Enabled)
JPL1 LAN1 Enable/Disable Pins 1-2 (Enabled)
JPME2
Intel
®
Manufacturing Mode
Pins 1-2 (Normal)
JWD1 Watch Dog Function Enable Pins 1-2 (RST)
POWER BUTTON Internal Power Button Push Button Switch
RESET BUTTON Onboard System Reset Button Push Button Switch
Connectors
*PCIE M.2 Connector 1 shares with U.2 Connector 1. (When M.2 device is plugged into PCIE M.2 Connector 1, U.1 connector 1 will be automatically disabled.)
*PCIE M.2 Connector 2 shares with SATA4/5. (When M.2 device is plugged into PCIE M.2 Connector 2, SATA4/5 will be automatically disabled.)
