Supermicro H11SSL-I User Manual

45
Chapter 2: Installation
Speaker (JD1)
If you wish to use an external speaker, attach an external speaker to pins 6~7. See the table
below for pin denitions.
Speaker Connector
Pin Denitions
Pin Setting Denition
Pins 1~2 Power LED
Pins 6~7 External Speaker
Power SMB Header (PWRI2C)
Power System Management Bus (I2C) header monitors power supply, fan and system
temperatures. See the table below for pin denitions.
Power SMB Header
Pin Denitions
Pin# Denition
1 Clock
2 Data
3 PWR Fail
4 Ground
5 +3.3V
12V 8-pin Auxilliary Power Connector (JPWR1)
JPWR1 is an 8-pin ATX power input to provide auxiliary power to the processor. Refer to the
table below for pin denitions.
12V 8-pin Power Connector
Pin Denitions
Pins Denition
1 through 4 Ground
5 through 8 +12V
12V 4-pin Auxilliary Power Connector (JPW1)
JPW1 is an 4-pin ATX power input to provide auxiliary power to peripheral devices. Refer to
the table below for pin denitions.
12V 4-pin Power Connector
Pin Denitions
Pins Denition
1 through 2 Ground
3 through 4 +12V

Supermicro H11SSL-I Specifications

General

ECC	Yes
Memory voltage	1.2 V
Memory channels	Octa-channel
Memory slots type	-
Supported memory types	DDR4-SDRAM
Maximum internal memory	1024 GB
Supported memory clock speeds	2666 MHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of DIMM slots	8
PCI Express x8 (Gen 3.x) slots	3
Supported DIMM module capacities	8GB, 16GB, 32GB, 64GB, 128MB
BIOS type	AMI
ACPI version	5.1
BIOS memory size	128 Mbit
Wi-Fi	No
LAN controller	Intel I210, Realtek RTL8211E
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2500
Bundled software	Super Doctor 5 Watch Dog NMI SUM IPMI 2.0, KVM w/ dedicated LAN
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Component for	Server
Motherboard form factor	ATX
Number of SATA III connectors	12
Trusted Platform Module (TPM) version	1.2
Processor socket	Socket SP3
Processor manufacturer	AMD
Compatible processor series	AMD EPYC
Supported storage drive interfaces	SATA III
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	244 mm
Width	305 mm
