Supermicro H12SSL Series User Manual


Chapter 2: Installation
Onboard Fan Headers (FAN1~FAN5, FANA, FANB)
              

           

Fan Header
Pin Denitions
Pin# Denition
1 
2 
3 
4 
Disk-On-Module Power Connector (JSD1 & JSD2)


DOM Power
Pin Denitions
Pin# Denition
1 
2 
3 
I-SATA Ports (I-SATA0~I-SATA7), H12SSL-i/C/CT Only



SATA Connectors
Pin Denitions
Pin# Signal
1 
2 
3 
4 
 
 
 
2.7 Connectors

Supermicro H12SSL Series Specifications

General

Socket	Socket SP3
CPU Series	AMD EPYC 7002/7003 Series
Chipset	AMD SoC
Memory Support	DDR4 ECC Registered DIMM
Memory Slots	8 DIMM slots
Maximum Memory Capacity	2TB
PCIe Slots	7 x PCIe 4.0 x16 slots
Networking	Dual 10GBase-T with Intel X550-AT2
Storage	2x M.2 slots, M-Key, 2280/22110, PCI-E 4.0 x4
USB Ports	4 x USB 3.0, 2 x USB 2.0
Power Connectors	24-pin ATX, 2 x 8-pin EPS
