Supermicro H12SSL Series User Manual

39
Chapter 2: Installation
PCIe M.2 Connector (M.2-M1/M2)



TPM Header/Port 80 Connector (TPM Port)




           
.
Trusted Platform Module Header
Pin Denitions
Pin# Denition Pin# Denition
1  2 
3  4 
   
  8 
9  10 
11  12 
13  14 
   
  18 
19  20 

Supermicro H12SSL Series Specifications

General

Socket	Socket SP3
CPU Series	AMD EPYC 7002/7003 Series
Chipset	AMD SoC
Memory Support	DDR4 ECC Registered DIMM
Memory Slots	8 DIMM slots
Maximum Memory Capacity	2TB
PCIe Slots	7 x PCIe 4.0 x16 slots
Networking	Dual 10GBase-T with Intel X550-AT2
Storage	2x M.2 slots, M-Key, 2280/22110, PCI-E 4.0 x4
USB Ports	4 x USB 3.0, 2 x USB 2.0
Power Connectors	24-pin ATX, 2 x 8-pin EPS
