Super X11SCM-LN8F/-F and X11SCL-LN4F User's Manual
Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1 ~ JPL8 GLAN Enable Pins 1-2 (Enabled)
JPME2 ME Manufacturing Mode Pins 1-2 (Normal)
JWD1 Watchdog Timer Pins 1-2 (Reset)
LED Description Status
BMC_HB_LED BMC Heartbeat LED Blinking Green: BMC Normal
LED4 Unit Identier (UID) LED Solid Blue: Unit Identied
LED_PWR_SB Standby Power LED Solid Green: Power Supply On
PWR_LED Onboard Power LED Solid Green: System On
Connector Description
COM1 COM Header
FAN1 ~ FAN4
FANA, FANB
CPU/System Fan Headers
IPMI_LAN Dedicated IPMI LAN Port
I-SATA0 ~ I-SATA5
Intel® PCH SATA 3.0 Ports (with RAID 0, 1, 5, 10)
I-SATA4 and I-SATA5 supports SuperDOM
I-SGPIO1, I-SGPIO2 Serial Link General Purpose I/O Headers
JBAT1 Onboard Battery
JD1
Speaker Header
(Pins 1-4: Speaker; Pins 3-4: Onboard Buzzer)
JF1 Front Control Panel Header
JL1 Chassis Intrusion Header
JLED1 Onboard Power LED Header
JLD1 LAN3 ~ LAN4 Activity LED Connector
JLD2 LAN5 ~ LAN8 Activity LED Connector
JPW1 24-pin ATX Power Supply Connector
JPW2 8-pin Power Connector
JSD1, JSD2 SATA DOM Power Connectors
JSTBY1 Standby Power Header
JTPM1 Trusted Platform Module (TPM)/Port 80 Header
JUIDB1 Unit Identier (UID) Switch
LAN1 ~ LAN8
1GbE LAN Ports
X11SCM-LN8F: LAN1 ~ LAN8
X11SCM-F: LAN1 ~ LAN2
X11SCL-LN4F: LAN1 ~ LAN4
Notes: The table above is continued on the next page.
