Super X11SCM-LN8F/-F and X11SCL-LN4F User's Manual
Motherboard Features
CPU
•
Supports an Intel Xeon E-2200/2100, 9th/8th Generation Core i3, Pentium, and Celeron (Socket H4 - LGA 1151) series
processor with a thermal design power (TDP) of up to 95W and eight cores
Memory
•
Up to 128GB of unbuffered (UDIMM) DDR4 (288-pin) ECC memory with speeds of up to 2666MHz in four memory slots
Note: Memory speed support depends on the processor used in the system.
DIMM Size
• Up to 32GB at 1.2V
Note: For the latest CPU/memory updates, please refer to our website at http://www.supermicro.com/products/
motherboard.
Chipset
•
Intel C242: X11SCL-LN4F
• Intel C246: X11SCM-LN8F/-F
Expansion Slots
•
One (1) PCI-Express 3.0 x16 Slot (CPU SLOT6)
• One (1) M.2 slot for PCI-Express 3.0 x4 or SATA 3.0 x1 (Supports M-Key 2280 / 22110 and Intel Optane Memory)
**M.2-H_2: X11SCM-LN8F/-F supports both; X11SCL-LN4F supports only PCI-E 3.0 x4
• One (1) M.2 slot for PCI-Express 3.0 x4 (Supports M-Key 2280 / 22110 and Intel Optane Memory)
**M.2-P_1: X11SCM-LN8F/-F only
Network Controllers
•
X11SCM-LN8F: Eight (8) Intel i210 for 1GbE BASE-T Ports
• X11SCM-F: Two (2) Intel i210 for 1GbE BASE-T Ports
• X11SCL-LN4F: Four (4) Intel i210 for 1GbE BASE-T Ports
• One (1) Dedicated IPMI LAN located on the back I/O panel
Baseboard Management Controller (BMC)
•
ASpeed AST2500 BMC
Graphics
•
Graphics controller via ASpeed AST2500 BMC
I/O Devices
•
Serial (COM) Port • One (1) front accessible serial port header (COM1)
• SATA 3.0 • Six (6) SATA 3.0 ports at 6Gb/s (I-SATA 0~5 with RAID 0, 1, 5, 10)
• Video (VGA) Port • One (1) VGA connection on the back I/O panel
Motherboard Features
Notes: The table above is continued on the next page.
