Supermicro X11SCV-Q User Manual

11
Chapter 1: Introduction
Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JI2C1, JI2C2 PCI-E Slot SMBus (Data/Clock) Pins 2-3 (Disabled)
JPAC1 Audio Enable Pins 1-2 (Enable)
JPL1, JPL2 LAN1, LAN2 Enable/Disable Pins 1-2 (Enable)
JPME2 Manufacturing Mode Pins 1-2 (Normal)
JPT1 TPM Enable/Disable Pins 1-2 (Enable)
JWD1 Watch Dog Timer Pins 1-2 (Reset)
Connector Description
AUDIO FP Front Panel Audio Header
BT1 Onboard CMOS battery socket
COM1/2 COM1 and COM2 Ports (back panel)
COM3/4 COM3 and COM4 Headers
COM5/6 COM5 and COM6 Headers
DVI-D Digital Visual Interface Port (digital only)
EDP1 Embedded DisplayPort
FAN1 - FAN3 CPU/System Fan Headers (FAN1: CPU Fan)
HD AUDIO High Denition Audio Ports (back panel)
HDMI 2.0/DP High Denition Multimedia Interface/DisplayPort
I-SATA0 - I-SATA4
SATA 3.0 Ports
(-L: Only I-SATA0 - I-SATA3)
J11 PS2 Keyboard and Mouse Header
JD1 Speaker/Buzzer (Pins 1-4: Speaker)
JF1 Front Control Panel Header
JGP1, JGP2 General Purpose I/O Headers
JL1 Chassis Intrusion Header
JMD1 M.2 PCI-E 3.0 x1 CNVi Slot (E Key 2230)
JMD2
M.2 PCI-E 3.0 x4 Slot (M Key 2242/2280)
(-L: Not available)
JPH1 4-pin Power Connector for HDD
JPW1 24-pin ATX Power Connector
JPV1
12V 8-pin DC Power Connector (Required to provide extra power to the CPU, or as alternative
power for a special enclosure when the 24 pin ATX power is not in use)
JSD1 SATA DOM Power Connector
JTPM1 Trusted Platform Module (TPM)/Port 80 Connector
LAN1, LAN2 GbE LAN Ports
Note: The table above is continued on the next page.
