Super X13DEG-OAD User's Manual
Power Button
HDD Acitivity LED
Ground
Ground
P5V_USB
I2C Clock
Fail LED_N (OH/FF/PF)
19
Ground20
1
2
Reset/UID Button
P3V3_STBY
Power Fail LED_N
Standby LED_N
Power Fail LED_P
JF1
LAN-1 Activity LED (Aggregate all LAN)
I2C Data
UID LED_N
LAN-2 Activity LED
Power/RoT LED_N
P5V_USB
P5V_USB
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1
2
LAN1/LAN2 (NIC1/NIC2)
The NIC (Network Interface Controller) LED connection for LAN Port 1 is located on Pin 6 of
JF1, and the connection for LAN Port 2 is on Pin 5. Refer to the tables below.
LAN1/LAN2 LED
LED States
Color State
NIC 2: Blinking green LAN 2: Active
NIC 1: Blinking green LAN 1: Active
1. LAN 2 Activity LED
2. LAN 1 Activity LED
3. HDD Activity LED
3
HDD Activity LED
The HDD activity LED connection is located on Pin 7 of JF1. When this LED is blinking green,
it indicates HDD activity. Refer to the table below.
HDD LED
LED State
Color State
Blinking Green HDD Active
