Supero X10SLL-F User Manual

Chapter 1: Introduction
1-11
Serial (COM) Connections
One (1) Front Accessible Serial Port header(COM2)
(X10SLM-F/X10SLL-F)
One (1) Serial Port on the rear I/O Panel (COM1)
(X10SLM-F/X10SLL-F)
Super I/O
AST2400/AST1400 BMC (AXT2400 for -F models)
BIOS 128 Mb AMI BIOS
®
SPI Flash BIOS
Play and Plug (PnP0, DMI 2.3, PCI 2.3, ACPI 1.0/2.0/3.0,
USB Keyboard and SMBIOS
Power Conguration ACPI/ACPM Power Management
Main Switch Override Mechanism
Wake-On-LAN (WOL) Header
Keyboard Wake-up from Soft-Off
Power-on mode for AC power recovery
PC Health Monitoring CPU Monitoring
Onboard voltage monitors for CPU core, +3.3V, +5V,-12V,
+12V, +3.3V Stdby, +5V Stdby, VBAT, Memory, VCORE
for CPU
CPU 3-phase switching voltage regulator
CPU/System overheat LED and control
CPU Thermal Trip support
Thermal Monitor 2 (TM2) support
Fan Control
Fan status monitoring with rmware 4-pin fan speed con-
trol via IPMI interface
Low noise fan speed control
System Management PECI (Platform Environment Conguration Interface) 2.0
support (for -F models)
System resource alert via SuperDoctor
®
III
SuperDoctor® III, Watch Dog, NMI
Chassis Intrusion header and detection
CD Utilities BIOS ash upgrade utility
Other ROHS 6/6 (Full Compliance, Lead Free)
Dimensions Micro ATX form factor (9.6" x 9.6") (243.84 mm x 243.84
mm)
Note: For IPMI Conguration Instructions, please refer to the Embedded
IPMI Conguration User's Guide available @ http://www.supermicro.com/
support/manuals/.
