Chapter 1: Introduction
1-13
1-2 Chipset Overview
The X10SLM-F_X10SLL-(F/SF/S) supports Intel® Xeon® E3-1200 v3 and 4th
Gen Core i3, Pentium and Celeron processors in an LGA 1150 (H3) Socket. Built
upon the functionality and the capability of the C224/C222 Express chipset, the
motherboard provides substantial enhancement to system performance and storage
capability for high performance platforms in a sleek package.
The high-speed Direct Media Interface (DMI) featured in the Intel C224/C222
Express chipset supports high-speed Direct Media Interface (DMI) for chip-to-chip
true isochronous communication. In addition, the X10SLM-F_X10SLL-(F/SF/S)
also features a TCO timer which allows the system to recover from a software/
hardware lock and perform tasks, including Function Disable and Intruder Detect.
Intel C224/C222 Express Chipset Features
•Direct Media Interface (up 4 GB/s transfer, Full Duplex)
•Intel® Matrix Storage Technology and Intel Rapid Storage Technology
•Dual NAND Interface
•Intel I/O Virtualization (VT-d) Support
•Intel Trusted Execution Technology Support
•PCI Express 2.0 Interface (up to 5.0 GT/s)
•SATA Controller (up to 6Gb/sec)
•Advanced Host Controller Interface (AHCI)
Note: The Intel C224 Express PCH is supported by the X10SLM Series.
The C222 Express chip is supported by the X10SLL Series.
