X9DRL-3F/X9DRL-iF Motherboard User’s Manual
SATA Connections (X9DRL-iF Only)
• SATA Two (2) SATA 3.0 Ports
(I-SATA 0/1)
Four (4) SATA 2.0 Ports
(1-SATA 2~5)
Four (4) SATA 2.0 Ports
(S-SATA0~3 from SCU)
• RAID Support RAID 0, 1, 5, 10
IPMI 2.0
• IPMI 2.0 supported by the WPCM450R BMC
Serial (COM) Port
• Two (2) Fast UART 16550 Connection: 9-pin RS-
232 port
Peripheral
Devices
USB Devices
• Four (4) USB ports on the rear I/O panel (USB 6/7,
USB 8/9),
• Four (4) USB connections for front access (USB 0/1,
USB 2/3),
• One (1) Type A USB connection for front access
(USB 4)
BIOS
• 16MB SPI AMI BIOS
®
SM Flash BIOS
• APM 1.2, PCI 2.3, ACPI 1.0/2.0/3.0/4.0, USB Key-
board, Plug & Play (PnP) and SMBIOS 2.3
Power
• ACPI/ACPM Power Management
Management
• Main switch override mechanism
• Power-on mode for AC power recovery
• Intel
®
Intelligent Power Node Manager (Available
when the NMView Utility is installed)
• Management Engine
PC Health
CPU Monitoring
Monitoring
• Onboard voltage monitors for +3.3V, 3.3VSB, +5V,
+5V SB, +12V, Chipset Voltage, and Battery Voltage.
• CPU/System overheat LED and control
• CPU Thermal Trip support
• Thermal Monitor 2 (TM2) support
