RMK-700 Operating Manual
15
Measurement of Contact Lens Base Curve(CLBC Mode)
It is the mode to measure base curve of contact lens (concave surface).
(1) Enter the Mode
In K&R mode, press the MODE button until "CLBC MODE" is displayed
in the top of the display.。
(2) Attach Contact Lens
Put water in the concave section of contact lens holder at backside of the
TEST Model Eye and place the contact lens on the holder with the
concave surface facing upward. Take care that the contact lens not drop
(3) Attach the test Model Eye
Remove the chin rest paper. Fix the Model Eye attached with contact lens
using fixation pin.
(4) Perform Focusing
Looking at he monitor, incline the operation joystick to right or left, and
turn the operation joystick so there is“+” in the screen.
(5) Measurement
Measure
ment of
Curvatur
e
#
Indicati
ng low
reliabilit
y
Measured
value of low
reliability
Measure
again
+
OUT
Exceed
ing
measur
able
range
Radius of
curvature
exceeds
9.4mm
Impossible
to measure
- OUT
Exceed
ing
measur
able
range
Radius of
curvature
is less than
6.5mm
