THE SAFETY WARNINGS BELOW CANNOT COVER ALL POSSIBLE SITUATIONS THAT MAY
OCCUR. THESE BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO PROTECT
AGAINST PERSONAL INJURY TO THE OPERATOR OR OTHER PERSONNEL IN THE AREA, AS
WELL AS DAMAGE TO THE EQUIPMENT. READ AND UNDERSTAND THESE WARNINGS BEFORE
USING EQUIPMENT.
Keep tool away from children, and DO NOT allow children near work area.
Do not allow children or untrained personnel to handle this nailer.
DO NOT operate this nailer while tired, or under the influence of drugs,
alcohol, or medication that makes you drowsy.
Never point the nailer at yourself or others - always assume that the
nailer is loaded, and proceed with caution.
Wear safety glasses and ear protection. The nailer operator and all
personnel in the work area must wear safety glasses that protect the front and side, to avoid eye
injury. Ear plugs should be worn to avoid
hearing damage.
If operator will be working in a situation where overhead work will
be done (i.e. on a ladder, stairs, or scaffolding) a hard hat must be worn.
Never wear loose clothing or jewelry because it can get caught
in the moving parts of this nailer. Make sure long hair is covered,
To avoid getting it caught in nailer.
Keep the nailer pointed away from yourself and others at all times. Keep hands and all body
parts away from rear area of nailer (near air hose) to guard against injury. Keep hands and feet
away from firing head during use.
Keep proper balance and footing at all times - do not over-reach.
Never use oxygen, bottled gas or any type of combustible fuel as
a power source - it can cause an explosion and serious injury.
Do not use near flammable liquids or gases - the stapler sparks
During operation, and could cause an explosion and serious injury.
Use an air hose that will withstand at least 150 psi, OR 150% of the maximum pressure of the
compressor.
Never connect this tool to compressed air if the pressure could exceed 200 psi, as the nailer
could burst. Use only clean, dry, regulated compressed air, with pressure not exceeding 120 psi.
Do not use a non-relieving coupler with this nailer - if used, the nailer could remain charged with
air after disconnecting, and would still be able to drive a nail even after being disconnected. The
nailer and air hose must have a coupling so that all pressure is removed from the nailer when the
coupling is disconnected.
Do not depress the trigger or safety mechanism while loading nails - accidental firing of a nail
can occur. Keep your fingers away from the trigger when not firing nails. Always keep the nailer
pointed downward during loading.
Do not use an air hose that is too long - nailer operator can trip over it. Make sure all connections
are tight.
(Warnings continued next page)
Improper use of this nailer can result in death or serious injury.
This manual contains important information about product safety.
Read and understand this entire manual before operating this nailer
IMPORTANT SAFETY WARNINGS:
! DANGER
AIR
Troubleshooting
The following form lists the common operating system with problems and solutions. Please
read the form carefully and follow it.
WARNING: If any of the following symptoms appear during your operation, stop using the tool
immediately, or serious personal injury could result. Only a qualified person or an authorized
service center can perform repairs or replacement of tool. Disconnect tool from air supply
before attempting repair or adjustment. When replacing O-rings or cylinders, lubricate with air
tool oil before assembly.
Problem
Nailer operates but no nail is
driven.
Week drive. Slow to cycle.
Drives too deep.
Skipping nails, Intermittent
feed.
Nails jam, Driven nail is bent
Drives properly at normal
speed but does not drive fully
drive at faster nailing speed.
Check
Check for jam
Check feeder function
Ribbon spring damaged or week?
Check for proper nails
Check air pressure
Drive blade worn?
Piston O-ring worn or damaged?
Check air pressure.
Check for proper nails.
Check nail feeder function.
Ribbon spring worn or damaged?
Piston O-ring cut or worn out?
Check for proper nails.
Drive blade worn?
Check inside hose diameter.
Correction
Clear a nail jam.
Clean and lubricate.
Replace ribbon spring.
Use correct nails.
Increase air pressure. Do not
exceed 120 psi.
Use pneumatic oil.
Replace tool.
Reduce air pressure 70-100 psi.
Use only recommended nails.
Clean and lubricate.
Replace ribbon spring.
Use pneumatic oil.
Replace tool.
Use only recommended nails.
Replace tool.
Use larger air hose.
