592860 4/20 | 80-000224_INST_C
Attaching The Rack To Your Bike
1. Install the rack onto the appropriate rack mounts on the frame using the 16mm cap screws, and grease the threads lightly.
Leave the screws slightly loose until height and angle adjustments are made. Remember: The upper hardware slides on the
rack tube to adjust for the width of the frame braze-ons.
2. Mount your rack as low as possible. Always maintain a minimum 6mm clearance between the bottom of the rack and
the rear tire. This will keep the center of gravity low when the rack is loaded.
3. Use torque wrench with 4mm bit to tighten the lower clamp hardware to 3–4Nm when the proper height is attained.
4. Adjust the rack angle, so rack is parallel to the ground.
5. Use torque wrench with 4mm bit to tighten the M8 set screws to 6Nm when the proper angle is attained.
6. Use torque wrench with 4mm bit to tighten the upper 16mm cap screws to 6Nm to finish the installation.
Ongoing Maintenance
WARNING: Improper installation of bolts may lead to product failure, causing serious injury. Do not exceed specified torque
values. Periodically inspect bolts and retighten if required.
Frequently check to make sure that all of the rack hardware is properly torqued per these instructions and the rack maintains
position 6mm above the rear wheel. Check to make sure that the rack mounting bolts are properly tightened and secure the rack
to the bicycle frame. Periodically check for any signs of cracking or failure and discontinue use if rack is damaged.
Limited Warranty
This Surly product is warranted against defects in materials and workmanship for one year from the date of retail purchase
of the product, subject to the limitations detailed below. Save your dated receipt for proof of purchase.
This warranty does NOT cover the following:
• Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience
of the user or assembler
• Products that have been modified, neglected, used in competition or for commercial purposes, misused or abused,
involved in accidents or anything other than normal use
• Installation of components, parts or accessories not originally intended for or compatible with Surly product as sold
• Damage or deterioration to the paint, surface finish, aesthetics or appearance of the product
• Normal wear and tear
• Labor required to remove and/or refit and re-adjust the product within the bicycle assembly
This limited warranty is expressly limited to the repair or replacement of a defective product, at the option of Surly, and
is the sole remedy of the warranty. This limited warranty applies only to the original purchaser of the Surly product and is not
transferable. This warranty applies only to products purchased through an authorized dealer or distributor. In no event shall Surly
be liable for any loss, inconvenience or damage, whether direct, incidental, consequential, or otherwise resulting from breach of
any express or implied warranty or condition, of merchantability, fitness for a particular purpose, or otherwise with respect to our
products except as set forth herein.
This limited warranty gives the consumer specific legal rights, and those rights and other rights may vary from place
to place. This limited warranty does not affect your statutory rights.
Warranty Process
We will happily back up our products if there is a problem that is our fault. If you and your shop think your Surly
product is worthy of a warranty inspection, please return the product to the original place of purchase, accompanied
by a sales receipt.
TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR
IMPLIED WARRANTIES OR CONDITIONS INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE.
