4
CB-ONE Module Assembly
The CB-ONE Module is designed to fi t the Suunto SM-36 analog pressure gauges.
Before assembling the CB-ONE module the hose cover needs to be fi tted on the pressure hose. The hose cover ensures
that the SM-36 pressure gauge fi ts properly on the CB-ONE module.
If the Suunto Quick Release is used, the hose cover is not to be used (See section CB-ONE module assembly using the
SUUNTO Quick Release).
After attaching the hose cover the pressure hose and gauge are assembled on the CB-ONE front cover according to the
picture.
After the pressure gauge is in place the CB-ONE back cover (or alternatively the CB-71/SK-7/DS compass) is attached with
four screws.
