13-2
FUSES AND PROTECTED CIRCUITS
66J21-03E
FUSES
No. COLOR (AMPS) PROTECTED CIRCUIT
MAIN FUSE
BOX
(11) RED (50) ABS 1 ABS actuator fuse
In engine
compartment
(12) YELLOW (20) FI Main fuse
(13) – – Blank
(14) RED (10) H/L L Head light high beam fuse, left
(15) RED (10) H/L R Head light high beam fuse, right
(16) RED (10) H/L Head light fuse
(17) GREEN (40) ST MTR Starter motor fuse
(18) GREEN (40) IGN Ignition fuse
(19) BLUE (15) H/L LO L Head light low beam fuse, left
(20) BLUE (15) H/L LO R Head light low beam fuse, right
