13-3
FUSES AND PROTECTED CIRCUITS
66J21-03E
64J158
FUSES IN FUSE BOX FUSES IN FUSE BOX
(A) BLUE (15) STOP Stop lamp fuse (M) RED (7.5) ST SIG Starter signal fuse
(B) – – Blank (N) YELLOW (20) RR BLOW Blank
(C) BLUE (15) ACC 3 Accessory socket fuse (O) CLEAR (25) S/R Sun roof motor fuse
(D) RED (10) CRUISE Cruise control fuse (P) BLUE (15) DOME Dome lamp fuse
(E) BLUE (15) ACC 2 Cigar or Accessory socket fuse (Q) RED (10) TAIL Tail light fuse
(F) YELLOW (20) WIP Wiper fuse (R) YELLOW (20) D/L Door lock actuator fuse
(G) BLUE (15) IG2 SIG Ignition signal & Seat heater fuse (S) BLUE (15) ACC Radio, Remote door mirror fuse
(H) RED (10) BACK Back lamp fuse (T) RED (10) METER Meter fuse
(I) RED (10) ABS/ESP ABS or ESP controller fuse (U) YELLOW (20) IG COIL Ignition coil fuse
(J) BLUE (15) A/B Air bag fuse (V) YELLOW (20) P/W T Power window fuse
(K) – – Blank (W) PINK (30) P/W Power window fuse
(L) BLUE (15) HAZ Hazard light fuse
SPARE SPARE SPARE
SPARE
USE THE DESIGNATED
FUSES AND RELAYS ONLY
SPARE SPARE
(A)(B)(C)(D)(E)(F)(G)(H)(I)(J)
(L)(M)(N)(O)(P)(Q)(R)(S)(T)(U)
(K)
(V)(W)
