Suzuki DF 50 - Engine Side Cover Shape Change

DF40/50 “K7” (’07) MODEL 19
ENGINE SIDE COVER
The side covers and securing screws have been changed in shape.
marked portion
30 mm 35 mm
7.2 mm
6.2 mm
15 mm
21 mm
7.0 mm
5.7 mm
25 mm 14 mm
Starboard side cover
Port side cover
