60
FUSE
1. Turn the ignition key to the “off” position.
2. Remove the motor cover.
3. Remove the fuse box cover and pull off the
fuse.
NOTE:
Use the fuse puller at the back of fuse box
cover, when the fuse is pulled off and installed.
4. Inspect the fuse and replace with the new
fuse if needed.
Fuse box
cover
Normal fuse
Main fuse (30A)
Blown fuse
NOTE:
If a fuse is blown, try to determine the root
cause and correct it.
If the cause is not corrected, the fuse may be
blown again.
WARNING
If you replace a blown fuse with a fuse having
a different amperage rating or with a substi-
tute such as aluminum foil or a wire, extensive
electrical system damage and a fire may
result.
Always replace a blown fuse with a fuse of the
same type and rating.
NOTICE
If a new fuse blows in a short time after instal-
lation, you may have a major electrical system
problem.
Consult your SUZUKI marine dealer.
