Suzuki DL1000 Owner's Manual

7-12
SPARK PLUG REMOVAL
To remove the spark plugs, follow
the procedure below:
Front Side
1. Remove the bolts 1.
2. Remove the fasteners.
3. Remove the screws 2.
4. Remove the radiator mounting
bolt 3 and slide the radiator
forward.
5. Pull off the spark plug cap.
6. Remove the spark plug with a
spark plug wrench.
NOTE: Be careful not to damage
the radiator fins.
WARNING
A hot radiator and hot engine
can burn you.
Wait until the radiator and
engine are cool enough to
touch with bare hands before
starting this work.

Suzuki DL1000 Specifications

General

Displacement	996cc
Compression Ratio	11.3:1
Final Drive	Chain
Starter	Electric
Bore x Stroke	98.0mm x 66.0mm
Transmission	6-speed
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Fuel Tank Capacity	22.0 L (5.8 US gal)
Ground Clearance	165 mm (6.5 in)
Ignition	Electronic
Fuel System	Electronic Fuel Injection
