6-54
The main fuse is located under the
seat. To access the fuse, remove the
seat by referring to the SEAT LOCK
AND HELMET HOLDERS section.
One 30A spare fuse is located inside
the fuse box cover.
The fuses are located inside of the left
frame cover.
1. Remove the bolt.
2. Unhook the hooks and remove the
left frame cover.
Two spare fuses (one 10A and one
15A) are provided inside the fuse box.
NOTE: Remove the fuse box before
opening box lid and replacing fuses.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki GSX1250FA and is the answer not in the manual?

Suzuki GSX1250FA Specifications

General IconGeneral
Engine Type4-stroke, liquid-cooled, DOHC
Engine Displacement1255 cc
Bore x Stroke79.0 mm x 64.0 mm
Compression Ratio10.5:1
Fuel SystemFuel injection
IgnitionElectronic ignition (transistorized)
StarterElectric
Transmission6-speed constant mesh
Final DriveChain
Front SuspensionTelescopic, coil spring, oil damped
Rear SuspensionLink type, coil spring, oil damped
Front BrakesDisc, twin
Rear BrakesDisc
Front Tire Size120/70ZR17M/C (58W), tubeless
Rear Tire Size180/55ZR17M/C (73W), tubeless
Overall Length2130 mm
Overall Width790 mm
Wheelbase1485 mm
Seat Height805 mm
Curb Weight257 kg
Fuel Tank Capacity19.0 L
