8-44 SERVICING INFORMATION
ITEM N
.
m kgf
.
m lb-ft
Piston cooling oil jet bolt 10 1.0 7.0
Oil jet (For generator) 5 0.5 3.5
Oil pump mounting bolt 10 1.0 7.0
Conrod bearing cap bolt (Initial) 35 3.5 25.5
(Final) 67 6.7 48.5
Bearing retainer screw 8 0.8 6.0
Cam chain guide retainer screw 8 0.8 6.0
Balancer arm bolt 10 1.0 7.0
Balancer cover bolt 10 1.0 7.0
Breather pipe bolt 10 1.0 7.0
Oil strainer bolt 10 1.0 7.0
Oil pan bolt 10 1.0 7.0
Oil pipe bolt [M:6] 10 1.0 7.0
Oil pipe union bolt [M:14] 28 2.8 20.5
FI ASYSTEM AND INTAKE AIR SYSTEM
ITEM N
.
m kgf
.
m lb-ft
Camshaft position sensor mounting bolt 8 0.8 6.0
Intake air temperature sensor 18 1.8 13.0
Fuel pressure check plug 10 1.0 7.0
Fuel pressure regulator mounting screw 3 0.3 2.0
Fuel filter cap mounting screw 3 0.3 2.0
Fuel delivery pipe mounting screw 5 0.5 3.5
Fuel pump mounting screw 5 0.5 3.5
COOLING AND LUBRICATION SYSTEM
ITEM N
.
m kgf
.
m lb-ft
Impeller securing bolt 8 0.8 6.0
Water pump cover bolt 6 0.6 4.5
Water pump mounting bolt 10 1.0 7.0
Cooling fan thermo-switch 17 1.7 12.5
Engine coolant temperature sensor 18 1.8 13.0
Thermostat case bolt 10 1.0 7.0
Oil cooler hose bolt 10 1.0 7.0
CHASSIS
ITEM N
.
m kgf
.
m lb-ft
Steering stem head nut 90 9.0 65.0
Steering stem lock nut 80 8.0 58.0
Steering damper bolt 23 2.3 16.6
Front fork upper clamp bolt 23 2.3 16.5
Front fork lower clamp bolt 23 2.3 16.5
Front fork cap bolt 23 2.3 16.5
Front fork inner rod lock nut 29 2.9 20.8
Front fork damper rod bolt 40 4.0 29.0
Front axle 100 10.0 72.5
Front axle pinch bolt 23 2.3 16.5
Handlebar clamp bolt 10 1.0 7.0
Handlebar holder nut 35 3.5 25.5

Suzuki GSX1300R HAYABUSA Specifications

General

Displacement	1340cc
Bore x Stroke	81.0 mm x 65.0 mm
Compression Ratio	12.5:1
Fuel System	Fuel injection
Transmission	6-speed constant mesh
Overall Width	735 mm
Overall Height	1165 mm
Wheelbase	1480 mm
Ignition	Electronic ignition (transistorized)
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	190/50ZR17M/C (73W), tubeless
Starter	Electric
Final Drive	Chain
Overall Length	2180 mm
Seat Height	800 mm
Curb Weight	264 kg
Fuel Tank Capacity	20.0L
Ground Clearance	125 mm
Engine Type	4-stroke, liquid-cooled, DOHC
