LT160K3/K4 (’03, ’04-MODELS) LT-F160K3/K4/K5 (’03, ’04, ’05-MODELS) 15-16
ELECTRICAL
Unit: mm (in)
WATTAGE
Unit: W
ITEM SPECIFICATION NOTE
Spark plug
Type
NGK: DPR7EA-9
ND: X22EPR-U9
Gap
0.8 – 0.9
(0.031 – 0.035)
Spark performance Over 8 (0.3) at 1 atm.
Ignition coil resistance
Primary 0.1 – 1.0 Ω
Terminal –
Ground
Secondary 10 – 25 kΩ
Plug cap –
Ground
Magneto coil resistance Pulser 380 – 600 Ω BI – G
Charging 0.5 – 1.2 Ω Y – Y
Generator no-load voltage More than 55 V (AC) at 5 000 r/min.
Generator Max. output Approx. 150 W at 5 000 r/min.
Regulated voltage 13.5 – 15.5 V at 5 000 r/min.
Starter relay resistance 3 – 7 Ω
Battery Type designation YB9A-A
Capacity 12 V 32.4 kC (9 Ah)/10 HR
Standard
electrolyte S.G.
1.28 at 20°C (68°F)
Fuse size 15 A
ITEM SPECIFICATION
Headlight HI 45
LO 45
Brake light/Taillight
*21/5
Reverse indicator light 3.4
Neutral indicator light 3.4
