15-17 LT160K3/K4 (’03, ’04-MODELS) LT-F160K3/K4/K5 (’03, ’04, ’05-MODELS)
BRAKE + WHEEL
Unit: mm (in)
SUSPENSION
TIRE PRESSURE
ITEM STANDARD/SPECIFICATION LIMIT
Front brake lever free travel 30
(1.2)
—
Rear brake pedal free travel 20 – 30
(0.8 – 1.2)
—
Brake drum I.D.
Front —
120.7
(4.75)
Rear —
150.7
(5.93)
Brake lining thickness
—
1.5
(0.06)
Steering angle Inside 41° —
Outside 30° —
Turning radius 2.4 m (7.9 ft) —
Toe-in (with 75 kg, 165 lbs) 3 – 11 (0.1 – 0.4) —
Caster 8° —
Trail 31 (1.2) —
Wheel axle runout
Rear —
8.0
(0.31)
Wheel rim size Front 8 × 5.5 AT —
Rear 8 × 8.0 AT —
Tire size Front AT 20 × 7-8 ✩ —
Rear AT 22 × 10-8 ✩ —
Tire tread depth
Front
4.0
(0.16)
—
Rear
4.0
(0.16)
—
ITEM STANDARD LIMIT NOTE
Rear shock absorber spring
setting
2nd position —
Front wheel travel 80
(3.1)
—
Rear wheel travel 90
(3.5)
—
Swingarm pivot shaft runout
—
0.6
(0.02)
COLD INFLATION
TIRE PRESSURE
LOAD CAPACITY
130 kg (285 lbs)
kPa kgf/cm
2
psi
FRONT 25 0.25 3.6
REAR 20 0.20 2.9
