6A2-50 ENGINE MECHANICAL (K9K ENGINE)
10) Remove tappet (1) from cylinder head.
Installation
1) Apply engine oil around tappet (1), and then install it to cylin-
der head.
2) Remove oil, old sealant and dust from sealing surfaces. After
cleaning, apply sealant “A” to cylinder head (1) sealing sur-
face area as shown in figure.
“A”: Loctite 5181®
3) Install camshaft to cylinder head as follows.
a) Direct key groove (2) upward by turning crankshaft (1)
clockwise.
CAUTION:
Note original position in which each tappet was installed
when valve lash (clearance) adjustment is not necessary.
If each tappet is not installed to original position, engine
will spoil its original performance.
1
1
“a”: 1 mm (0.04 in.)
1
2
To Next Page
