8-1
EMERGENCY SERVICE
74LH0-74E
Tire Changing Tool
Spare tire and tire changing tool
74LHT0806
52KM117
The jack, is stowed just under the spare
tire in the luggage compartment.
74LHT08031
52KM136
To remove the spare tire, turn its bolt (1)
counterclockwise by using the tools as
shown in the figure and remove it.
74LHT0802
To remove the jack, turn its shaft counter-
clockwise and pull the jack out of the stor-
age bracket.
To stow the jack, place it in the storage
bracket and turn the shaft clockwise until
the jack is securely held in place.
(1)
NOTICE
When stowing the jack, place the
shaft facing to the left as shown in
the illustration. Otherwise the jack
cannot be held securely in place in
the storage bracket.
Jacking Instructions: 5
