2-20
BEFORE DRIVING
80SS5-01E
81A009
To open a window, push the top part of the
switch. To close the window, lift up the top
part of the switch.
The driver’s window has AUTO-DOWN
and AUTO-UP (if equipped) features for
greater convenience (at toll booths or
drive-through restaurants, for example).
These features allow the driver to open or
close the window without holding the win-
dow switch in DOWN or UP position. Press
down or lift up the driver’s window switch
completely and release it. To stop the win-
dow before it reaches the FULL-DOWN or
FULL-UP position, pull up or push down
the switch briefly.
Lock switch (Type A)
80SS02050
Lock switch (Type B)
52RM20240
The driver’s door also has a lock switch for
the passenger’s window(s). When you
push in the lock switch, the passenger’s
window(s) cannot be raised or lowered by
operating any of the switches (2), (3), (4)
or (5). To restore normal operation, release
the lock switch by pushing it again.
NOTE:
If you drive with one of the rear windows
open, you may hear a loud sound caused
by air vibration. To reduce the sound, open
the driver’s or front passenger’s window, or
narrow the rear window opening.
WARNING
• You should always lock the pas-
senger’s window operation when
there are children in the vehicle.
Children can be seriously injured if
they get part of their body caught
by the window during operation.
• To avoid injuring an occupant by
window entrapment, check that no
part of the occupant’s body such as
hands or head is in the path of the
electric windows when closing
them.
• Always remove the ignition key or
take the keyless push start system
remote controller with you when
leaving the vehicle even only for a
short time. Also do not leave chil-
dren alone in a parked vehicle.
Unattended children could use the
electric window switches and get
trapped by the window.
