Suzuki SWIFT 2022 Series - Spark Plugs

7-50
INSPECTION AND MAINTENANCE
80SS5-01E
(For K14D engine model)
80SM020
1) Loosen the bolt (1) and pull the duct
(2).
80SM019
2) Unclamp the side clamps (3) and
remove the element from the air
cleaner case. If it appears to be dirty,
replace it with a new one. Be careful
not to disconnect the hose (4).
3) Reinstall the air cleaner case and
clamp the side clamps securely.
4) Insert the duct (2). Tighten the bolt (1)
securely.
Spark plugs
Spark plug replacement and inspec-
tion
(Except for K12C engine model)
Since special procedures, materials and
tools are required, it is recommended that
you trust this job to an authorized SUZUKI
dealer.
(For K12C engine model)
81PN236
To access the spark plug:
1) Disconnect the coupler (1) while push-
ing the release lever.
2) Remove the bolt (2).
3) Pull out the ignition coil (3) straight.
(2)
(1)
(3)
(4)
(1)
(3)
(2)
EXAMPLE
