7-82
INSPECTION AND MAINTENANCE
80SS5-01E
52RM70470
3) Slide the blade out as shown.
NOTE:
Do not flex the wiper blade frame end more
than necessary. If you do, it can break off.
52RM70480
(1) Retainer
4) If the new blade is provided without the
two metal retainers, move them from
the old blade to the new one.
5) Install the new blade in the reverse
order of removal.
Check that the blade is properly
retained by all the hooks.
6) Reinstall wiper frame to arm in the
reverse order of removal.
Windshield washer fluid
80JM078
Check that there is washer fluid in the tank.
Refill it if necessary. Use a good quality
windshield washer fluid, diluted with water
as necessary.
(1)
(1)
WARNING
Do not use radiator antifreeze in the
windshield washer reservoir. This
can severely impair visibility when
sprayed on the windshield, and also
can damage your vehicle’s paint.
NOTICE
Damage may result if the washer
motor is operated with no fluid in the
washer tank.
