7-42
INSPECTION AND MAINTENANCE
80SS5-01E
Refilling
52RM60020
Remove the oil filler cap and pour oil slowly
through the filler hole to bring the oil level
to the upper limit on the dipstick. Be careful
not to overfill the oil. Too much oil is almost
as bad as too little oil. After refilling, start the
engine and allow it to idle for about a min-
ute. Stop the engine, wait about 5 minutes
and check the oil level again.
Changing engine oil and filter
Drain the engine oil while the engine is still
warm.
52RM70010
1) Remove the bolts and screws, and then
remove the engine undercover.
52RM60030
2) Remove the oil filler cap.
3) Place a drain pan under the drain plug.
4) Using a wrench, remove the drain plug
and drain the engine oil.
CAUTION
The engine oil temperature may be
high enough to burn your fingers
when the drain plug is loosened. Wait
until the drain plug is cool enough to
touch with your bare hands.
To Next Page
