7-72
INSPECTION AND MAINTENANCE
80SS5-01E
Headlights
LED type
Since special procedures are required, it is
recommended that you take your vehicle
to an authorized SUZUKI dealer for light
replacement.
Halogen type
52RM70220
(1) Bulb
52RM70320
1) Open the engine hood while the engine
is stopped. Disconnect the coupler (2).
Remove the sealing rubber (3) by pull-
ing the grip (4).
52RM70330
2) Push the retaining spring (5) forward
and unhook it. Then remove the bulb.
Install a new bulb in the reverse order
of removal.
52RM70230
NOTE:
You can see the position of retaining spring
from the hole of headlight.
(1)
To Next Page
