Suzuki SWIFT 2022 Series User Manual

8-14
EMERGENCY SERVICE
80SS5-01E
K12M engine models
52RS80010
K14D engine models
80SM018
3) Connect jump leads as follows:
1. Connect one end of the first jump
lead to the positive (+) terminal of
the discharged battery (1).
2. Connect the other end to the positive
(+) terminal of the booster battery
(2).
3. Connect one end of the second jump
lead to the negative (–) terminal of
the booster battery (2).
4. Make the final connection to an
unpainted, heavy metal part (i.e.
engine mount bolt (3)) of the engine
of the vehicle with the discharged
battery (1).
4) If the booster battery you are using is
fitted to another vehicle, start the
engine of the vehicle with the booster
battery. Run the engine at moderate
speed.
5) Start the engine of the vehicle with the
discharged battery.
6) Remove the jump leads in the exact
reverse order in which you connected
them.
(3)
(1)
32
4
1
(2)
EXAMPLE
(2)
4
(1)
1
32
(3)
EXAMPLE
WARNING
Never connect the jump lead directly
to the negative (–) terminal of the dis-
charged battery, or an explosion may
occur.
CAUTION
Connect the jump lead to the engine
mount bolt securely. If the jump lead
disconnects from the engine mount
bolt because of vibration at the start
of the engine, the jump lead could be
caught in the drive belts.
