7-39
INSPECTION AND MAINTENANCE
57RK0-14E
License plate light
52RM70070
1) Remove the cover (1) by turning it
counterclockwise.
76MH0A126
2) To remove and install the bulb of the
license plate light (2), simply pull out or
push in the bulb.
High-mount stop light
LED is used. It is recommended that you
take your vehicle to an authorized SUZUKI
dealer for bulb replacement since special
procedures are required.
Interior light
Remove the lens by using a flat-bladed
screwdriver covered with a soft cloth as
shown. To install it, simply push it back in.
Front
76MH0A139
Luggage compartment (if equipped)
52RM70281
(1)
