Suzuki Swift Owner's Manual

7-41
INSPECTION AND MAINTENANCE
57RK0-14E
3) Pull the locked end of the wiper blade
firmly to unlock the blade and slide the
blade out as shown.
52RM70520
(3) Retainer
4) If the new blade is provided without the
two metal retainers (3), move them
from the old blade to the new one.
61MM0B098 61MM0A212
(A) Up
(B) Down
NOTE:
When you install the metal retainers (3),
make sure the direction of metal retainers
as shown in the above illustrations.
(3)
(3)
EXAMPLE
(3)
(3)
EXAMPLE
EXAMPLE
(3)
(A)
(B)
