Suzuki VZ1500 User Manual

7-34
CLUTCH ADJUSTMENT
Clutch cable play should be 10 – 15 mm
(0.4 – 0.6 in) measured at the clutch
lever end. Adjust clutch cable play
according to the following procedure:
Minor Adjustment
10 – 15 mm
(0.4 – 0.6 in)
Loosen the lock nut 2. Turn the clutch
cable adjuster 1 to provide the speci-
fied play.
Major Adjustment
1. Remove the 3 bolts. Remove the
cover.

Suzuki VZ1500 Specifications

General

Manufacturer	Suzuki
Model	VZ1500
Displacement	1462cc
Compression Ratio	9.5:1
Fuel System	Fuel injection
Starter	Electric
Final Drive	Shaft Drive
Front Suspension	Telescopic, coil spring, oil damped
Ignition	Electronic ignition (Transistorized)
Transmission	5-speed
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Disc
Rear Brakes	Disc
Ground Clearance	140 mm
