DRIVELINE/AXLE 4-19
• Remove the final driven gear bearing D and oil seal E with
the special tools.
# 09941-64511: Bearing remover
09930-30104: Sliding shaft
$
• Remove the final drive gear bearing with the special tools.
# 09923-74511: Bearing remover
09930-30104: Sliding shaft
$
NOTE:
If no abnormal noise, the bearing removal is not necessary.
• Remove the oil seal F and O-ring G from the bearing stopper.
$
INSPECTION
Inspect the removed parts for the following abnormalities.
* Drive and driven bevel gear damage or wear
* Improper tooth contact
* Abnormal noise of bearings
* Bearing damage or wear
* Oil seal damage or wear
* Propeller shaft spline damage or wear
* Spring for damage or fatigue
The removed bearing and oil seal must be replaced
with new ones.
The removed bearing must be replaced with a new one.
The removed oil seal and O-ring must be replaced with
new ones.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
