Suzuki VZR1800 2008 User Manual

9-12 CHASSIS
• Install the wheel bearings with the special tools as follows.
% 09941-34513: Bearing/Steering race installer set
09924-84510: Bearing installer set
$
• Install the dust seal with the special tool.
% 09913-70210: Bearing installer set (52 mm)
• Apply SUZUKI SUPER GREASE “A” to the dust seal lip.
' 99000-25010: SUZUKI SUPER GREASE “A”
or equivalent
BRAKE DISC
• Make sure that the brake disc is clean and free of any greasy
matter.
• Apply THREAD LOCK SUPER to the disc mounting bolts and
tighten them to the specified torque.
# Brake disc bolt: 23 N·m (2.3 kgf-m, 16.5 lb-ft)
( 99000-32130: THREAD LOCK SUPER “1360”
or equivalent
First install the left wheel bearing, then install the
spacer and right wheel bearing.
The sealed cover of the bearing must face outside.
LH RH LH RH
Clearance

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
