MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1X FRONT ASSEMBLY E6163UD 1VM321745
A15 CHASSIS ASSEMBLY E6163UD 1VM321747
A16 TOP CASE E6150UD 1VM320703
A21# MODEL NO. LABEL E6164UH ----------
A22 LABEL BAR CODE E5900UD ----------
A23 TEL NUMBER LABEL H9811UD(SV2000) ----------
A29 LABEL EAS L0951UB ----------
1B1 DVD MECHA E6(FG LESS 2) N79F3JVM N79F3JVM
2B5 REINFORCE PLATE E6160UD 1VM421017
2L011 SCREW P-TIGHT 3X10 BIND HEAD+ GBEP3100
2L021 SCREW P-TIGHT 3X11 BIND HEAD+ GBMP3110
2L031 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L041 SCREW B-TIGHT M3X8 BIND HEAD + GBKB3080
2L081 SCREW P-TIGHT M3X8 WASHER+ GCMP3080
2L105 P-TIGHT SCREW 3X8 BIND + GBMP3080
PACKING
S1 GIFT BOX CARTON E6163UD 1VM321749
S2 SIDE PAD E6160UD 1VM220264
S4 SET BAG E5960UD 1VM420147
ACCESSORIES
X1 REMOTE CONTROL UNIT NB070UD NB070UD
X2 DRY BATTERY R6P/2S XB0M451T0001
X4 ACCESSORY BAG E5700UD 0VM415576
X5 AV CORD TSCKA-Y/RW100 WPZ0102TM015
X10# OWNERS MANUAL E6163UD 1VMN21566
