20050823 1-16-1 E6164EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DVD MAIN CBA UNIT
AV CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DVD MAIN CBA UNIT N79F1JUP
Ref. No. Description Part No.
AV CBA
Consists of the following:
1VSA10581
CAPACITORS
C1001# METALIZED FILM CAP. 0.047µF/ 250V M CT2E473MS037
C1003 ELECTROLYTIC CAPACITOR
ZT250TA2R2M6BB
CA2E2R2DYG02
C1004 ELECTROLYTIC CAPACITOR
ZR200TA820M12BB
CA2D820DYG01
C1005 CERAMIC CAP. CH J 56pF/500V CCD2JJPCH560
C1006# SAFETY CAP. 2200pF/250V CCD2EMA0E222
C1007 CAP ALUMINUM ELECTOLYTIC 1000µF/ 6.3V
M
CE0KMASDL102
C1009 CAP ALUMINUM ELECTOLYTIC 1000µF/ 6.3V
M
CE0KMASDL102
C1010 CERAMIC CAP CH J 680pF/50V CA1J681TU008
C1013 FILM CAP.(P) 0.0033µF/ 50V J CA1J332MS029
C1014 CAP ALUMINUM ELECTOLYTIC 1000µF/ 6.3V
M
CE0KMASDL102
C1017 CERAMIC CAP.(AX) Y M 0.01µF/ 16V CCA1CMT0Y103
C1022 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1029 CERAMIC CAP.(AX) X K 2200pF/16V CCA1CKT0X222
C1034 CAP ALUMINUM ELECTOLYTIC 470µF/ 6.3V M CE0KMASDL471
C1035 CAP ALUMINUM ELECTOLYTIC 1000µF/ 16V
M
CE1CMASDL102
C1036 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1037 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V CHD1JZ30F104
C1038 CAP ALUMINUM ELECTOLYTIC 470µF/ 6.3V M CE0KMASDL471
C1039 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V CHD1JZ30F104
C1047 FILM CAP.(P) 0.01µF/ 100V J CA2A103MS029
C1048 ELECTROLYTIC CAP. 220µF/ 16V M CE1CMASDL221
C1050 CAP ALUMINUM ELECTOLYTIC 220µF/ 6.3V M CE0KMASDL221
C1201 CAP ALUMINUM ELECTOLYTIC 10µF/ 16V M CE1CMASDL100
C1202 CAP ALUMINUM ELECTOLYTIC 10µF/ 16V M CE1CMASDL100
C1205 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1206 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1207 CHIP CERAMIC CAP.(1608) CH J 47pF/50V CHD1JJ3CH470
C1208 CHIP CERAMIC CAP.(1608) CH J 47pF/50V CHD1JJ3CH470
C1221 CAP ALUMINUM ELECTOLYTIC 10µF/ 16V M CE1CMASDL100
C1222 CAP ALUMINUM ELECTOLYTIC 10µF/ 16V M CE1CMASDL100
C1240 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
C1245 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V CHD1JZ30F104
C1246 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V CHD1JZ30F104
C1247 CAP ALUMINUM ELECTOLYTIC 470µF/ 6.3V M CE0KMASDL471
C1249 CAP ALUMINUM ELECTOLYTIC 47µF/ 16V M CE1CMASDL470
C1351 CHIP CERAMIC CAP.(1608) B K 0.1µF/ 25V CHD1EK30B104
C1352 ELECTROLYTIC CAP. 47µF/ 6.3V M H7 CE0KMASSL470
C1354 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C1361 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V CHD1JZ30F104
C1394 CAP ALUMINUM ELECTOLYTIC 47µF/ 10V M CE1AMASDL470
C1402 CAP ALUMINUM ELECTOLYTIC 470µF/ 6.3V M CE0KMASDL471
C1403 CHIP CERAMIC CAP.(1608) B K 0.33µF/ 10V CHD1AK30B334
C1422 CHIP CERAMIC CAP.(1608) B K 0.1µF/ 25V CHD1EK30B104
C1423 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1443 CAP ALUMINUM ELECTOLYTIC 1000µF/ 6.3V
M
CE0KMASDL102
C1524 CAP ALUMINUM ELECTOLYTIC 100µF/ 6.3V M CE0KMASDL101
C1535 CHIP CERAMIC CAP.(1608) B K 0.01µF/ 50V CHD1JK30B103
C1536 ELECTROLYTIC CAP. 22µF/ 6.3V M H7 CE0KMASSL220
C1537 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V CHD1JZ30F104
C2031 CAP ALUMINUM ELECTOLYTIC 100µF/ 6.3V M CE0KMASDL101
C2032 CHIP CERAMIC CAP.(1608) F Z 0.1µF/ 50V CHD1JZ30F104
C2034 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
CONNECTORS
CN1001 22P FFC AV PCB TO MAIN WX1E5900-001
CN1601 11P FFC AV PCB TO MAIN PCB WX1E6160-001
DIODES
D1001 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1002 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1004 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1005 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1006 SCHOTTKY BARRIER DIODE SB140 NDQZ000SB140
D1008 SCHOTTKY BARRIER DIODE SB140 NDQZ000SB140
D1011 RECTIFIER DIODE BA157 NDQZ000BA157
D1012 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1018 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1024 SWITCHING DIODE 1N4148M NDTZ01N4148M
D1030 RECTIFIER DIODE FR302 NDWZ000FR302
D1046 ZENER DIODE DZ-5.6BSCT265 NDTC0DZ5R6BS
D1047 ZENER DIODE DZ-5.1BSBT265 NDTB0DZ5R1BS
D1048 ZENER DIODE DZ-13BSBT265 NDTB00DZ13BS
D1053 PCB JUMPER D0.6-P10.0 JW10.0T
D1054 PCB JUMPER D0.6-P10.0 JW10.0T
D1058 SCHOTTKY BARRIER DIODE SB140 NDQZ000SB140
D1059 PCB JUMPER D0.6-P10.0 JW10.0T
D1073 PCB JUMPER D0.6-P5.0 JW5.0T
D1301 ZENER DIODE DZ-5.6BSBT265 NDTB0DZ5R6BS
D2010 LED(RED) 204HD/E NPQZ00204HDE
ICS
IC1001# PHOTOCOUPLER LTV-817B-F NPEB0LTV817F
IC1002 VOLTAGE REGULATOR LD1117SC-R NSZBA0TSS229
IC1006 IC SHUNT REGULATOR KIA431-AT NSZLA0TJY001
IC1201 IC OP AMP KIA4558P NSZBA0SJY004
IC1403 DRIVER FOR DVD MM1636XWRE QSZBA0TMM108
COILS
L1001# LINE FILTER 20MH SA-00911 LLBG00ZSA003
L1007 CHOKE COIL 22µH-K LLBD00PKV021
Ref. No. Description Part No.
