Quantum - Tool Recognition
Maintenance
Doc-0001374, Rev B
Sida 22
3. Remove the seal between the cover and lower part.
4. Replace battery in the unit.
Make sure to only use original batteries from SVAB. The unit willnot work
with ordinary 1.5 V batteries.
5. Install new seal [1] between cover and lower part.
Make sure that the seal ts the groove properly.
6. Put the cover back.
Make sure to turn the cover in correct position so the notch [2] ts
the battery.
7. Reinstall the 2 screws. Tightening torque 0.8 Nm.
1
2
