Main parts
Quantum hub
The hub consists of following main parts:
1. CAN1 / 8-36 VDC
2. I/O
3. CAN2
4. Diodes
5. Name plate
2
1
3
4
5
000503
TRM (tool Recognition Module)
The TRM consists of following main parts:
1. Screw
2. Cover
3. Seal
4. Battery
5. Lower part
