Sven PRO 800 - 3. Package Contents; 4. Operating Principle; 5. Description

ENG
4
Uninterruptible
Power Supply
3. PACKAGE CONTENTS
• Uninterruptible power supply — 1 pc
• Software CD disk (for Pro 650 (LCD, USB)/1000 (USB)/1500 (LCD, USB) models) — 1 pc
• Interface cable (for Pro 650 (LCD, USB)/1000 (USB)/1500 (LCD, USB) models) — 1 pc
• User manual — 1 pc
• Warranty card — 1 pc
4. OPERATING PRINCIPLE
• Line-interactive UPS’s provide perfect protection of PCs and peripherals. If there are drops
ofpower supply in the mains, the device connected to the UPS is powered by battery via in-
verter converting +12/24V DC voltage into 220 V AC voltage, which allows to save data and shut
down the operation of the system properly.
• Voltage mains supply goes through a lter to AVR module (Automatic Voltage Regulator). Volt-
age is increased or reduced if necessary to correspond to standard 220 V voltage, then voltag
issupplied to the connected equipment. At the same time the charging unit charges the battery.
5. DESCRIPTION
a
: Mains operation indicator (green). Lights when the UPS is turned on and the mains voltage
is within the normal limits.
b
: Battery status indicator (yellow). Intermittent illumination — when the battery is charging,
continuous light — the battery is charged.
c
: Inverter indicator (red). Lights when the UPS switches to inverter mode (battery operation).
d
: UPS switch-on button.
e Network operation mode.
f Battery operation mode.
g Output voltage.
h Load indicator.
i LCD display.
j Battery capacity indicator.
k Graphic input voltage level indicator: HIGH, NORMAL, LOW.
l Output plug.
m Power cable.
Attention! Before the rst start-up of the UPS itisnecessary to charge the battery for at least
12 hours without load.
