Specifications
• Supports: IEEE 803.3 and IEEE 803.3u
• Supports: IEEE 802.11b, IEEE 802.11g
• Maximum wireless data transfer speed: 54Mbps
• Supports: DHCP (dynamic IP), PPTP, Static IP, PPPoE, L2TP
• 1 x WAN, 4 x LAN RJ-45 UTP ports
• Supports: WEP/WPA./WPA2/802.1X data encryption
• Built-in Firewall and Port Forwarding
• Removable reverse SMA Antenna 5 dBi
• 2 to 3 x Extended Range
• Supports: VPN pass through
• Web-based configuration
• Not operating system dependent
Front view
Status Status Meaning
Power
Off The router is switched off
Lit The router is switched on
System
Lit The router is starting up
Blinking The router is operating correctly
Off The router has a hardware error
Link/Act WAN
and 1 to 4
Off No device is connected to this port
Lit A computer or other network device is connected to this port
Blinking There is data traffic between the router and the connected device
WLAN
Off The wireless part is switched off
Blinking The wireless part is active
