11
Throttle joystick (from Down to Up controls the ying height)
Slightly push up the throttle joystick to raise
the drone.
Pull down Throttle joystick to low the drone.
Drone will maintain current height when
throttle joystick stays at neutral position.
YAW direction control
Slightly pull left joystick to RIGHT to execute
clockwise rotation.
Slightly pull left joystick to LEFT to execute
counter-clockwise rotation.
The drone will keep current YAW direction
when the left joystick stays at neutral
position.
AILERON control
Up - Fly Forward
Down - Fly Backward
Left - Fly Left
Right - Fly Right
The drone will keep current position when
the right joystick stays at neutral position in
GPS mode.
4.2.1.4 Left joystick is for throttle and nose direction (YAW)
4.2.1.5 Right Joystick is for AILERON control (Fly Forward | Fly Backward | Fly Left | Fly Right).
