4.2 FLIGHT GUIDE
4.2.1 RADIO CONTROLLER OPERATIONS
4.2.1.1 Return-Home
Attention: During returning and descending, drone nose & aileron joystick are controllable for a better
landing location, Throttle is unavailable under Auto Return-Home mode.
SWC1 SWC2 SWC3
SWB1
SWB2
Normal
Return-Home
ATTI Mode
Circle Flight
GPS Mode
Return-Home Switch
SWC1
SWC2
SWC3
Flight Mode switch ( SWC1, SWC2, SWC3)
VRC, VRD is a gear switch to adjust the Roll/Pitch of Gimbal to get a better
photography angle, please refer to 4.6.2 for more details.
Remark: 18,19,20,21,25,26 are spare buttons for extra usage if any. The default Throttle control is
American Mode (Left Joystick), Right throttle (Japanese Mode) is available.
4.2.1.2Flight Mode switch explained
4.2.1.3 Gimbal controller
SWB1 SWB2
