SWELLPRO SPLASH DRONE - Setup, Calibration, and Safety; Propeller and Battery Management

©2016 SwellPro All Rights Reserved
15
Propeller Propeller with silver spinner Propeller with black spinner
Graphic
Installation Graphic
Assembly Location Motor with silkprinting ‘CCW’ Motor with silkprinting ‘CW’
Take out the 4pcs original 12inch self-tighten carbon ber propellers. Install the 2pcs propellers with
silver spinner onto CCW motors; Install the 2pcs propeller with black spinner onto CW motors. Tighten
them.
Props are self-tighten design without the need for extra hardware or tools.
The special propeller design makes it impossible to install the wrong propellers as two are CW and
the other two are CCW.
Please check to ensure all Props are in good shape with no damage or nicks before every ight.
Aging & damaged Props must be replaced to safely y the Splash Drone.
NEVER touch the rotating propellers.
Please be sure to ALWAYS use only original 12inch propellers to guarantee good y experience.
4.2.4 PROPELLER
4.2.4.1 Installation
Notice :
4.2.4.2 Uninstall Propeller
NEVER try to remove the propellers from the drone while motors are turning and is not locked properly.
DO NOT put the battery into water, re or heated space; please keep the battery away from source of
water and re.
Battery should be stored in a cool and dry environment.
The Battery temperature will be high temporarily after each use. Don’t start recharging until the
battery cools down to room temperature.
4.2.5 BATTERY
4.2.5.1 Usage & Cautions
The battery is specially designed for Splash Drone, with 4S 5200mAh capacity, 14.8V and
charge-discharge management functionality.
