Press "End" button to enter into OSD data
interface, all the ight data will be shown on the
controller screen, including at-sight battery
voltage, ying speed, GPS signal, etc.
Flight Speed (m/s)
Ascending(+) /Descending(-) speed ( m/s)
Throttle
At-sight voltage of the DRONE battery ( V )
Latitude
Longitude
The relative height between current point and the take-o point
The ground distance from current point to take-o point
GPS Signal level
NULL, indicate the Sensitivity of Receiver
Flight Mode
Flying angle of drone Nose
Flying angle of moving forward(+)/ Backward(-)
Flying angle of moving to Right(+)/ Left(-)
OSD data on controller screen
4.2.3.2 KEY word Introduction
Attention:
1. Under normal ight, to prevent mis-operation, the controller screen will be locked automatically
when the pilot does not press the buttons up to 20 seconds. A long press on the right PUSH button to
unlock the screen again.
2. When the controller screen is in OSD display, the system will not auto lock the screen.
ELEV
THRO
VOLT
LATI
LONG
ALT
DIST
GPS
RSSI
MODE
YAW
Pitch
Roll
Menu Introduction
Rate
